Pipe Cutting Machine for Square Cuts and Weld Bevels on Site
A hand-held torch cannot cut a pipe square, and it certainly cannot cut a consistent bevel. A pipe cutting machine fixes the torch to the pipe and drives it around at a steady speed, so the cut is square, the bevel angle is constant and the edge is ready for fit-up without grinding. The TUBOCUT-CS does this with a chain that wraps around the pipe and a motorised carriage that rides on it.
Because the chain is extendable, one machine covers 100 mm pipe in the fabrication shop and 2000 mm penstocks in the field. It runs from 220 V or 110 V and takes either an injector-type oxy-fuel torch or a plasma torch.
Accuracy
Square cuts, every time
The chain holds the carriage on a fixed circumferential path; the cut cannot wander.
Bevel
Weld-ready bevels
Torch angle adjustable up to 45° for single-V preparation in one pass.
Process
Oxy-fuel or plasma
Fit the injector torch for gas cutting, or mount a plasma torch for stainless and thin wall.
Portable
Shop and site
220/110 V, remote speed control — works beside a generator in the field.
How it works
From Pipe to Finished Edge in Four Steps
1
Wrap the chain
Lay the chain around the pipe, hook it to the carriage and tension it. For larger diameters, add chain links first.
2
Set the torch
Mount the oxy-fuel or plasma torch, set square or the bevel angle up to 45°, and adjust nozzle-to-pipe distance.
3
Set the speed
Choose 50–1150 mm/min on the dial or remote to match wall thickness (5–100 mm) and process.
4
Cut
Pre-heat, start cutting and switch on the drive. The carriage travels the full circumference and the edge comes off clean, with no second operation.
Speed is held constant by SCR control of the 20 W, 10,000 rpm drive motor, so the kerf stays uniform all the way round — the difference between a cut you can weld straight away and one you have to grind.
Why buyers choose it
What Changes When the Torch Rides on a Chain
Problem solved
“Our pipe ends never fit up square.”
A chain-guided cut is square to the pipe axis, so the joint closes with an even root gap.
Problem solved
“Bevelling by hand takes forever.”
Set 30° or 37.5° once; the machine bevels the full circumference in one pass while the operator prepares the next pipe.
Problem solved
“Every pipe size needs a different tool.”
One carriage, one chain, extra links for bigger pipe. From 100 mm to 2000 mm and beyond.
Problem solved
“Site power is a generator.”
Low-power 220/110 V drive runs happily from a site genset; remote control keeps the operator clear of the cut.
Key features
Built Around a Chain
Extendable aluminium chain
Standard chain to about 650 mm pipe; add links for 2000 mm and larger — no upper limit.
Motorised SCR drive
20 W, 10,000 rpm motor with SCR speed control, 50–1150 mm/min.
Dial or remote speed control
Set and trim travel speed from the carriage or from the remote while the cut is running.
45° bevel adjustment
Torch holder tilts for square cuts and bevels up to 45°.
Injector-type torch
For oxy-acetylene or oxy-LPG cutting of 5–100 mm wall; plasma torch mountable.
420 × 280 × 550 mm
One-person carry; sets up anywhere a pipe can be reached.
Applications
Where the TUBOCUT-CS Works
Pipeline construction
Field bevelling and cutting of line pipe before welding.
Process piping & refineries
Square cuts and weld preps on carbon and stainless pipe (plasma).
Penstocks & large-diameter pipe
Extended chain for 2000 mm and larger shells.
Boilers & power plants
Header and tube-bank pipe preparation on site.
Shipbuilding
Pipe spool fabrication in the shop and on board.
Water & irrigation
MS pipe cutting and bevelling in the yard.
Oxy-acetyleneOxy-LPGPlasma (torch mountable)Carbon steelStainless steel (plasma)220 V / 110 V
In the box
Standard Scope of Supply
The TUBOCUT-CS is supplied ready to cut; the chain length, torch type and any optional items for your order are confirmed on the quotation.
Motorised carriage with SCR drive
Speed dial and remote control.
Chain for pipes up to approx. 650 mm
Additional links available for larger diameters.
Torch holder with bevel adjustment
With injector-type cutting torch.
Power cable and a test certificate
Gas supply, hoses and regulators are customer-supplied.
Optional: extra chain links, plasma torch mounting, longer control cable.
Related machines: for a cutter that holds itself on the pipe magnetically, see the magnetic pipe cutting machine; for straight and circular cuts on plate with a plasma or oxy-fuel torch, the portable cutting trolley.
Why buy from CRUXWELD
Engineered in India, Supported Worldwide
45+ years of welding & cutting expertise
Designed and tested by CRUXWELD engineers; our technical team answers your questions on WhatsApp.
ISO 9001:2015
Every machine is inspected and run-tested before dispatch.
GeM Registered OEM Manufacturer
Tender-ready documentation for government, PSU and institutional buyers.
Pan-India supply, export ready
Dispatch across India and export packing for overseas orders; chain links, nozzles and spares in stock.
Specifications
TUBOCUT-CS Technical Data
| Parameter | TUBOCUT-CS |
|---|
| Model | TUBOCUT-CS |
| Input voltage | AC 220 V / 110 V, 50/60 Hz |
| Effective pipe diameter | 100 mm onwards (no upper limit with additional chain links) |
| Cutting thickness (wall) | 5 – 100 mm |
| Cutting shape | Square and bevel |
| Cut / bevel angle | Variable up to 45° |
| Cutting speed | 50 – 1150 mm/min |
| Drive method | Motorised, chain-driven |
| Motor | 20 W, 10,000 rpm |
| Speed control | SCR; adjustment by dial or remote |
| Cutting torch | Injector type (oxy-fuel); plasma torch mountable |
| Dimensions (L × W × H) | 420 × 280 × 550 mm |
| Weight | 16.5 kg |
Specifications are subject to improvement without notice; the quotation and test certificate supplied with the machine are the governing documents. Warranty terms are stated on the quotation / invoice.
