Plasma Cut 40

FINELINE 40
1 Star2 Stars3 Stars4 Stars5 Stars (3 votes, average: 4.67 out of 5)

Fineline 40 is an ultra-compact plasma cutter with an excellent starting technique. It is a perfect need for conductive metal up to 10mm thickness. At the output of 40A, it makes a precision cutting at a low intensity which makes it ideal for workshops and car body-making shops. FINELINE 40 is known for its portability, and it excels in precision cutting.

Features

Key features

  • The compact, portable, lightweight, and powerful FINELINE 40 is the first choice to cut with precision up to 10 mm steel with minimal distortion.
  • The equipment incorporates HF-free starting voltage resulting in penetrating rusted and painted surfaces and improving the consumable’s life.
  • The FINELINE40 is preferred for the high-speed and precise cutting of both sheet metal and plates. A large fan is incorporated to dissipate the heat leading to superior results and extended life of the equipment.
  • It is compact, lightweight, generator friendly, and weighs only 9 kg.
  • Cruxweld supplies are compact, and powerful, with an excellent result of cutting and precision in quality. It is the best instrument available in the market. It is the best equipment to invest in for your workshop and industries.
  • The entire range of Cruxweld comes with semi-Zener inverter technology making it 30% lighter, handy, compact, portable, and easy to operate.
  • The transistor bridge technology provides continuous current rectification leading to efficient cutting and power consumption reaching 85%.
  • It has a feature to protect from overheating, and overloading, and stable arc control for fine cuts.
  • It is laden with pure copper toroidal transformer.

Specifications

Model FINELINE 40
Input voltage AC220v-240v±15%
Phase Single
Frequency 50/60 Hz
Rated input capacity 5.5 KVA
Rated input current 25.6 A
Rated output voltage 96 V
Cutting current range  20-40 A
No load voltage 270 V
Cutting current @60% duty cycle 20 A
Power factor, Cosθ 0.93
Efficiency 85 %
Degree of protection IP21
Insulation  H
Cutting capacity 0.5-10 mm
Main fuse 16 A
Air flow pressure 4-5 Bar (75 psi)
Air consumption 15 l/min
Power source cooling Forced air
Torch cooling Air-cooled
Generator safe 6.5 KVA recommended
Dimensions (LxWxH) 370x160x290 mm
Weight  8 kg

Accessories

Plasma cut standard accessories include:

  • Air plasma cutting torch (complete set)
  • Air regulator
  • Grounding cable clamp
  • Input power lead
  • Tips, electrodes, cups & rings
  • Product manual

Description

The Cruxweld a plasma cutting machine manufacturer in India makes very compact, inverter based, and is capable of outperforming its competition. This welding machine is better and cheaper than Oxyacetylene. There is less cleaning, less noxious gas emission, less fire hazard, less maintenance, less work, and a better, cleaner margin at cut and faster. The consumables and parts include cutting tips, reversible electrodes, swirl ring, and shield cup. The torch used have all these fitted here and air regulator and hose connectors. The thermal and overload protection is assured by a cooling fan, long power cord, torch cord, and ground cord.

The plasma cutting machine in India is based on the principle of the fourth state of matter i.e. plasma. The other three states include solid, liquid, and gas. The one state change from one to another by the temperature used in the process. The solid is ice and with the rise in temperature, it changes into a liquid. The further rise in temperature leads to the next stage of matter i.e. from liquid to gas. The increase in further temperature leads to the fourth state called plasma. When in the process of plasma cutting the temperature at the metal site increased by a strong arc formed by an electric source of a single phase leading to the melting of metal. The inert gas used here once passed through a nozzle by its pressure takes away the molten metal and makes a very neat and clean cut.

The machine of plasma cut 40 is used in automotive industries, scrapping processes, fabrication units, and construction sites. This machine can cut steel, stainless steel, copper, brass, and aluminum. We manufacture high-quality welding sets with the best raw material, very precise, accurate, stable, portable, and best of design after long research. We have a team of hard-working, enthusiastic, and technically very skilled team for our manufacturing unit. Our technical team works tirelessly and can manufacture the required machine designated for a particular job in any industry and take care of welding machine prices in India.

Features

  • Simple, suitable to use and operate.
  • Appropriate for cutting all conducting equipment.
  • Separate selector switch for checking ‘Air Pressure’.
  • Arc factor electronic control for outstanding cutting quality.
  • Distortion-free, dross-free, burr-free, narrow kerf width, exceptionally clean cut.
  • A lightweight, compact, energy-efficient power source cut down overall cutting costs.
  • Cutting parameters stability within ±20% mains voltage fluctuations for long-lasting consumable parts.
  • Adjustable Post Flow cooling allows the torch to cool down after the cut and enhances consumable and torch life.
  • Air filter cum regulator assembly provided as standard accessories to ensure good cutting quality, compressed air for excellent cut quality.
  • Energy efficient outfit, built-in with high efficiency and high power factor power source, saves power consumption and reduces energy bills up to 30%.
